P Shape Customized For Facade System Thermal Barrier Polyamide strip

FOB Reference Price:Get Latest Price
$1.42 - $2.00 / Meters | 3000 Meter/Meters (Min. Order)
Type:
KXT
Samples - $1.00 /Meters, 1 Meters (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
KAXITE
Model Number:
KXT-P001
Color:
Black
Length:
6 meters/piece
Density:
1.30±0.05 g/cm3
Certificate:
TUV/SUD
Application:
aluminium window profiles
Material:
PA66 GF25
Thickness:
2mm
Product Name:
Customized For Facade System Thermal Barrier Polyamide strip
OEM Service:
Available
Supply Ability
Supply Ability:
10000000 Meter/Meters per Week
Packaging & Delivery
Packaging Details
polyamide66 thermal break strip
1. packaged in straight: 6 meters length per piece, 100 pieces as one bundle;
2. we support customized kinds of packaging for Customized For Facade System Thermal Barrier Polyamide strip.
Port
Shanghai

polyamide 66 thermal break strip

Customized For Facade SystemThermal Barrier Polyamide strip



Product Description



15 mm width customized thermal barrier polyamide material for facade system. Inserted in the thermal break aluminium profiles, and being the part of energy-saving window system for reducing heat conduction.  The thick and firm extruded polyamide profile has rather high mechanical performance than common plastics, ensuring the safety and beauty of curtain wall or facade system.

Technical Performance:

    The performance of thermal barrier strips are in line with the Chinese standard GB/T 23615.1-2009 and the European Standard EN 14024:2004, for KAXITE series, the performance is rather higher than the standard value.

Details of related standard:

  • GB/T 23615.1-2009 Accessorial material for architectural aluminum alloy profiles -- Part 1: Thermal barrier strip of polyamide
  • EN 14024-2004 Metal profiles with thermal barrier -- Mechanical performance Requirement, proof and tests for assessment
  • YS/T 437-2008 Aluminium profiles moment of inertia calculation methods and computing software requirements
  • JG/T 174-2005 Thermal barrier strips for construction industry
  • GB 5237.6 -2012 Wrought aluminium alloy extruded profiles for architecture -- Part 6: Thermal barrier profiles
  • GB/T 8478-2008 Aluminium windows and doors
  • GB/T 8484-2008 Graduation and test for thermal insulating properties of doors and windows
  • JG 175-2011 Insulating aluminum alloy profiles with thermal barrier for buildings
  • UL94 Standard for Tests for Flammability of Plastic Materials for Parts in Devices and Appliances
  • ASTM E84 Standard Test Method for Surface Burning Characteristics of Building Materials
  • NFPA 285 Standard Fire Test Method for Evaluation of Fire Propagation Characteristics of Exterior Non-Load-Bearing Wall Assemblies Containing Combustible Components

In 2015, we became the leader of the Chinese National Standard Committee (for revising of GB/T 23615.1-2009) .

(KAXITE Series)(made of pure new raw material of PA66), you can see the extremely better performance of thermal break polyamide strips as shown below:

Testing Result from CNAS:


Raw Materials & Granulation:
We granuled by ourselves to ensure the quality of raw material for PA66GF25 thermal insulation strips.
   What's the most important component in the raw material of Heat Insulation Profiles for windows & doors? Not Dupond, not extremely expensive fiberglass, it's Anti-aging agent and Antioxidants.
   Think what will happen if there's no such anti-aging agents or antioxidants? Heat Insulation Profiles for windows & doors may age fastly by exposing to wind and sun,and maybe  just for less than 10 years, the polymer profiles would break and glasses and windows will fall from such high curtain walls!! It's deadly! In addition, most completed raw materials in the market for thermal barriers manufacturers have no antioxidants which it must be added  just beacause of its high cost. We have our own capacity of granulation to ensure that our raw materials contain these important elements to avoid this situation happening!

ISO9001:2008 Manutacturing

Packaging & Shipping

 Good packaging and taking care of what you care about!


Our Services

OEM of Performance (Granulation)!

We support customizing any special performance of polyamide thermal break strips, even flame retardant required.
OEM of Shapes (cutting dies)!

Mostly we could finish the development of new products in 15 days.

It is hard for us to realize rather than think.  Most customers were upset that nobody could develop the shapes that they designed, some counterparts even came and looking for help to our workshop. We develop and cut new dies for our customer and we are so proud of that we never failed to develop any shape for our customers.



Service Advantages:
1,
Whichever shape you need for the heat insulation profiles for windows & doors , we can develop the mould in a short time and send you the samples. In fact, we have solved so many problems for our customers and they are satisfied.
2, We offer the most advancing laser marking machine for custmers if a special mark on the heat insulation strip is needed;
3, Here we offers most sizes from 10mm width to 60mm or even bigger heat insulating strips. So,what is  your best favor?
4, We provide matching equipment of PA66 thermal barrier profiles for customers for the corresponding service followed.

Storage Conditions:
It’s better to be stored in ventilated and dry environment, should be put horizontally, keep away from water, rain, heat, stress and avoid acids, alkalis and organic solvents meanwhile.

Packing:
Straight: 6 m / bar, 10~100 pieces per bundle as you like.
Roll bar: 500 meters / roll (only for the shape I and shape C pieces.



Company Information

An Energy-saving Materials Technology Company.

ABOUT KAXITE® TECHNOLOGY

Jiangyin Kaxite Energy-saving Materials Technology Co., Ltd (abb.: KAXITE TECHNOLOGY, KXT-TECH) was originally a family business, developing since 2001, now acting as a group, who has her own two divisions, Plastics Extrusion Division, Non-woven Division, and some high-tech cooperation projects, which supported by Nanjing University Of Science and Technology, Jiangyin Technology Bureau, Guangdong Nonferrous Metal Research Institute...

It is developing so fast and there're more than 150 employees in the group, with 2 factories, 3 offices, and 1 cooperated factory, 2 cooperated laboratories, all are located in China.

 Our Social Influence in the Industry of Energy-saving Materials.
National industrial symposia about aluminium thermal break profiles with polyamide thermal barrier strips always chaired by us.

Our successful projects:
Our Heat Insulation Profiles for windows & doors were used in most huge projects in China, such as Huimin District Procuratorate office, Heping District Tax Office,Shandong Province, China Netcom office building, Tianjin Global Village, Shenyang and Tai Wan Heng International Building, West Long Xi Hotel, Capital Airport Air War 3 floor, Nest, Shanghai Railway Station, Beijing Zhongguancun Science and Technology Park.

FAQ

 Question: Do you have MOQ requirement?

Re: No, but the extra cost for package and logistic will be charged.

 Question: Can we ask for samples?

Re: Yes, samples., will be free but express fee will be charged. Only 1 day needed for making samples ready.

 Question: Can we customize special shapes of polyamide profiles? How many days cost?

Re: Yes of course you can, we support cutting dies for our clients. Mostly from 15 days to 30 days. We ensure 100% successful.

 Question: Can we customize package styles, such as linear 5.8 meters, or 250 meters per roll?

Re: Yes.

 Question: Can we customize marks on thermal insulation strips?

Re: Yes.

 Question: Why your price is higher/lower than others?

Re: We have our own capacity of granulation, to ensure the quality of thermal insulation strips, please kindly be noted that you will get the best products from us under the same price in the market.

 Question: What is heat insulation profile?

  • Heat Insulation Profiles for windows & doors are made from resins that create a “thermal break” between the inner and outer surfaces of aluminum fenestrations.
  • Heat Insulation Profiles for windows & doors reduce heat loss or heat gain through the aluminum.
  • Heat Insulation Profiles for windows & doors improve the U-value characteristics of finished systems.
  • Heat Insulation Profiles for windows & doors are about energy conservation, U-values and government codes
  • 70% of aluminum fenestration systems produced in North America contain a thermal break
  • Primarily used in colder climates to reduce heat loss
  • Increasing use of thermal barriers to reduce heat gain and also reduce heat loss
  • Developers, architects and designers are demanding better performance in terms of power usage
  • Stricter government regulations to reduce power usage in buildings to combat environmental concerns
  • Aluminum, if it is to retain its market superiority in terms of its structural integrity, will have to achieve better performance in terms of U-values
  • The use of Heat Insulation Profiles for windows & doors will assist manufacturers to achieve improved LEED performance
The data in "What is Heat Insulation Profiles for windows & doors" was derived from the AAMA/WDMA U.S. Industry Statistical Review and Forecast - 2008/2009 (Published April 2009)
Product features?
1, The Heat Insulation Profiles for windows & doors were manufactured in line with Chinese national standards GB/T 23615.1-2009, with extremely high mechanical strength and withstand tensile shear stress, can be acted as the connecter to the hardware; if you need higher properties, please choose our kaxite series polyamide profiles which were produced with pure new raw materials, most of these PA66 particles were purchased from Dupond, and all the finished polyamide profiles were in compliance with the European standard UNE EN14024.
2, The linear expansion coefficient is close to aluminum, to ensure that when temperature changes, the Heat Insulation Profiles for windows & doors and aluminium profiles expanding in the same time to ensure fitting closely;
3, Highly heat distortion temperature, to meet subsequent processing on the surface of profiles;
4, High dimensional accuracy, ensuring airtight, watertight performance of the windows breaking thermo with polymer profiles;
5, Anti-aging, anti-UV performance, long using life;
6, Superior chemical resistance.
